About This Product
IG-LFP121.6-630E Overview
121.6V 630Ah 76.6kWh Battery
IG-LFP121.6-630E rack batteries are made from a deep cycle prismatic LiFePO4 battery that combines proprietary architecture, circuitry, assembly methods and battery management systems(BMS) that are modular, lightweight and callable for applications ranging from residential, commercial and industrial Energy Storage Total combos station installations.
Key Features
Safe and reliable LiFePO4
High cycle life and deep cycle capability
30-days delivery period
For on-grid and off-grid
10-year warranty & Technical support
Better price, bigger capacity
114 Series
Contact: info@ion-green.com www.ion-green.com
Product Information
Commercial and Industrial
Main Product Category
0 Components
Hardware Parts Available
Industrial Grade
Quality Certified
Need More Info?
Contact our experts for detailed specifications, pricing, and integration support for the IG-LFP121.6-630E.
Contact SalesComplete Data
Technical Specifications
ModelIG-LFP121.6-630E
Battery TypeLiFePO4
Nominal Voltage (V)121.6
Nominal Capacity (wh)76608
Usable Capacity (wh)68947.2
Cell＆ Method38S*14P*3
Dimension (mm)(LWH)2200*500*550mm
Weight(Kg)550-600 KG
Discharge Voltage(V)106.4
Charge Voltage(V)136.8
Charge Rate. Current/Power315A/38.3KW
Charge Max. Current/Power630A/76kW
Discharging Rate. Current/Power315A/38.3KW @ 0.5C / 630A/76.6Kw @ 1.0C
Discharging Max. Current/Power700/85Kw @30 sec
CommunicationRS232, RS485, CAN,WIFI(Optional), Bluetooth(Optional), HMI
Depth Of Discharge (%)90%
ExpansionUp to 12 units in parallel
Working Temperature Charge0~55℃
Working Temperature Discharge-20~55℃
Storage Temperature0~35℃
Short Circuit Current/ Duration Time600-800A,Delay time500μs
Cooling TypeAir forced
Protection LevelIP20
Monthly Self-discharge≤3%/month
Humidity≤60%ROH
Altitude(m)＜4000
Warranty10Years
Design Life＞15Years（25℃/77℉）
Cycle Life＞6000 cycles,25℃
Certification & Safety StandardUN38.3
Modular Ecosystem
Hardware Components
This variant is precision-engineered with high-grade components for industrial-strength reliability.
No Components
Detailed modular component specifications are available for verified partners.
Inquiry & PartnershipInterested in the
Interested in the
IG-LFP121.6-630E?
Our experts are ready to provide pricing, technical datasheets, and custom integration support for your project.
